Quick Draw Brand

A/C Bracket - Cummins R2.8 Compressor Mid Mount Bracket

No reviews yet Write a Review
8.00 LBS
16.00 (in)
16.00 (in)
8.00 (in)
Calculated at Checkout

Cummins R2.8 Mid Mount A/C Compressor Accessory Bracket

  • Weighs 7 Lbs
  • Works with existing Alternator and Power Steering pump
  • Fits PSC Power Steering Pump part# Sp333311-RHD
  • Has Multiple bolt locations so installer can Fabricate mounts for numerous Pumps/ Drives
  • Provided Prints for bolt hole positions for mount fabrication
  • Designed to use Cummins A/C compressor Part# 5295582
  • Moves compressor location up from factory Cummins Bracket
  • Made in the USA
  • Kit#AI-00010
  • A356-T6 Aluminum

Parts included in Kit:

Main Bracket  Part# QDB-210150
Qty 1: M10x1.5-55mm Socket Head Cap Screw (Block Mount)
Qty 3: M10x1.5-45mm Socket Head Cap Screw (Block Mount)
Rear P/S Bracket  Part# QDB-210020
Front P/S Bracket Part# QDB-210022
Slide Nut  Part# QDB-210073 (Rear P/S Bracket)
Qty 2: M10x1.5-35mm Socket Head Cap Screw (Rear P/S Bracket)
Qty 2: M10x1.5-45mm Socket Head Cap Screw (Front P/S Bracket)
Qty 2: M10x1.5-110mm Socket Head Cap Screw (A/C Compressor)
Qty 2: M10 Washer Flat (Front P/S Bracket)


Images of Mount Locations Provided

Weight: 7 lbs
